The PSC Tool Holder Series from Jiaxing XiRay Industrial Technology Co., Ltd. is an advanced tooling solution designed to meet the high-performance demands of modern machining industries. Featuring the innovative Polygon Shank Conical (PSC) interface, these tool holders provide exceptional rigidity, precision, and tool stability, making them the go-to choice for industries such as aerospace, automotive, medical devices, and electronics.
https://www.xiray-tools.com/psc-tool-holder-series/
Product Overview
The PSC Tool Holder Series utilizes the proprietary Polygon Shank Conical design, which is engineered to provide superior rigidity and vibration resistance. The unique polygonal shape maximizes the clamping surface area, resulting in a secure and stable connection between the tool holder and the machine spindle. This design minimizes deflection and tool chatter, even under extreme cutting conditions, improving the accuracy and surface finish of machined parts.
Manufactured to ISO 26623 standards, the PSC Tool Holder Series is compatible with a wide range of CNC machining centers, making it a versatile choice for various machining processes. It is suitable for use in turning, milling, drilling, and reaming, allowing manufacturers to streamline their tooling systems and improve machining efficiency.
Key Features & Benefits
Polygon Shank Conical Interface: The PSC interface provides a secure connection between the tool and spindle, offering enhanced rigidity, reduced vibration, and greater stability during high-speed machining. This results in improved cutting accuracy and extended tool life.
High-Speed Capability: Designed for high-speed machining, the PSC Tool Holder Series can operate at speeds up to 40,000 RPM, enabling manufacturers to achieve faster cycle times and higher productivity.
Precision Clamping System: The shrink-fit clamping system ensures uniform clamping force and minimized run-out, which further enhances the accuracy and repeatability of machining operations.
Versatile Applications: The PSC Tool Holder Series is suitable for static and live tooling applications, offering flexibility across various operations. Whether you're milling, turning, drilling, or reaming, these tool holders provide the precision and performance needed for a wide range of machining tasks.
Industry Applications
The PSC Tool Holder Series is designed to support the demands of high-precision machining in industries such as:
Aerospace: Ideal for machining critical aerospace components, including turbine blades, airframes, and landing gear, which require tight tolerances and superior performance.
Automotive: Perfect for producing engine parts, transmission components, and braking systems, where durability and high-precision cutting are essential.
Medical Devices: Used in the production of implants, surgical instruments, and medical equipment, ensuring the required precision and safety standards.
Electronics: Provides the micromachining capabilities needed for sensors, connectors, and micro-electromechanical systems (MEMS).
Why Choose XiRay’s PSC Tool Holder Series?
Exceptional Rigidity and Precision: The PSC design offers maximum tool stability, reducing tool deflection and enhancing cutting accuracy.
Durability and Tool Life: The vibration-resistant design ensures that tools stay in place during heavy-duty operations, extending tool life and reducing the frequency of tool replacements.
Improved Machining Efficiency: The high-speed capabilities of the PSC Tool Holder Series reduce cycle times and improve throughput, increasing overall productivity and reducing manufacturing costs.
Conclusion
The PSC Tool Holder Series by Jiaxing XiRay Industrial Technology Co., Ltd. is a cutting-edge solution for industries that demand precision, rigidity, and high-speed performance. Whether you are in aerospace, automotive, medical, or electronics, the PSC Tool Holder Series will optimize your machining processes, enhance tool performance, and improve the overall quality of your products. With its advanced design and versatile capabilities, this series is a must-have for manufacturers looking to stay ahead in a competitive market.
